Flat Die 300-800kg /H Biomass Wood Pellet Mill Sawdust Pellet Machine With CE Certificate
Product Description:
The flat die granulator uses solid waste such as corn stalks, wheat straw, straw, peanut shells, corn cobs, cotton stalks, soybean stalks, chaff, weeds, branches, leaves, sawdust, bark and other solid wastes as raw materials, after crushing , pressurized, densified, and shaped to become a small rod-shaped solid particle fuel. Pellet fuel is made by extruding sawdust, straw and other raw materials with pressing rollers and ring dies at room temperature. The density of the raw material is generally about 110-130kg/m3, and the density of the formed particles is greater than 1100kg/m3, which is convenient for transportation and storage, and at the same time, its combustion performance is improved
Working principle of flat die wood pellet machine:
The equipment is based on the inherent motion of the machine. The motor (or diesel engine) is used as the power to drive the gear to the main shaft. The powdery material is plasticized, the protein is denatured by temperature, and extruded from the die hole under the extrusion of the pressure roller. The required particle length can be obtained by adjusting the cutter, and then the formed particles are passed through the throwing tray. It is sent out of the machine through the discharge port.
1. How to use: Start the machine, pour the mixture into the hopper, and form particles through the wire screen through the swinging action of the rotating drum, and fall into the container, such as crushed pieces
It should be added gradually, and it should not be filled up, so as to avoid excessive pressure and make the screen vulnerable.
2. Precautions: If the powder stagnates in the powder hopper, do not use your hands to shovel it, so as not to cause hand injury accidents, use a bamboo shovel or stop to work.
Features:
- 1. Dry in and dry out, no need to dry. It adopts differential gear and universal joint transmission, low energy consumption, high output and convenient operation.
2. It adopts cold pressing forming technology, polishing and shaping process, beautiful appearance, simple and compact knot, wide applicability, small footprint and low noise.
3. It adopts multiple extrusion, high output, low energy consumption, low noise, low failure, and continuous production.
4 The flat die granulator is equipped with molds with various hole diameters, which are suitable for granulating different materials.
5. The flat die granulator adopts high-quality materials and shaft-connecting transmission device, and the key components are made of high-quality alloy steel materials, which are heat-treated in a vacuum furnace, and the service life is extended by 5-7 times
Technical Parameters:
| Model | Capacity (KG/H) | Power (KW) | Weight(kg) | Packing Size |
| 200B | 80-120 | 7.5 | 300 | 1050*480*1120 |
| 300B | 200-300 | 22 | 550 | 1310*610*1510 |
| 400B | 400-500 | 30 | 850 | 1460*710*1710 |
| 450B | 600-700 | 45 | 1150 | 1612*710*1710 |
| 550B | 700-800 | 55 | 1800 | 2300*800*1900 |
Support and Services:
Wood Pellet Mill Technical Support and Service
We provide best-in-class technical support and service for our wood pellet mill customers. Our experienced team can provide you with advice and guidance to ensure you get the most out of your product. We offer a range of services, including:
- Installation and setup assistance
- Troubleshooting and problem-solving
- Maintenance and repair
- In-depth product training
- Ongoing support and advice
For more information, please contact us at [Your Contact Information].
Applications:
Customization:
The main accessories of the machine
Packing and Shipping:
FAQ:
Q1. What is the brand name of this Wood Pellet Mill?
A1. The brand name of this Wood Pellet Mill is ZHONGDEBAO.
Q2. What is the model number of this Wood Pellet Mill?
A2. The model number of this Wood Pellet Mill is PMZL300B.
Q3. Where is this Wood Pellet Mill produced?
A3. This Wood Pellet Mill is produced in China.
Q4. What certifications does this Wood Pellet Mill have?
A4. This Wood Pellet Mill is certified with CE, SGS, and BV.
Q5. How much does one set of this Wood Pellet Mill cost?
A5. The cost of one set of this Wood Pellet Mill is negotiable.
