Capacity 100-800kg/H Wood Sawdust Pellet Making Machine Pellet Mill Machine Use For Fuel
Product Description:
Biomass pellet machine is a specialized molding machine used for creating pellet fuel out of various branches, wood chips, corn stalks, rice straw, wood bran, wood powder, sawdust and other agricultural wastes. These pellets can be used for various applications, such as fireplace, boiler, and biomass power plant.
This kind of molding machine is widely used for its convenience, high efficiency, and safety. With high capacity models, it can process a range of biomass materials into pellets in a shorter time. Its operation is simple and does not require any molding or pressed techniques, thus saving labor costs and increasing production efficiency. Additionally, its short production cycle guarantees pellets with uniform shape and size.
Biomass pellet machine provides environmental friendly solutions for pellet fuel production, and it is a cost-effective solution for both commercial and home users. Not only can it reduce energy consumption, but also reduce carbon emissions.
Features:
Our pellet machine, manufactured by us, adopts the mature and popular vertical ring die pellet machine on the market. As compared to the flat die, this model has several advantages, mainly in the following four areas:
1. In vertical direction, where the mold is placed flat and the sawdust enters the granulation mold from top to bottom. Thus the specific gravity of the sawdust is so light that it can rotate and be thrown around by the pressure wheel, resulting in an even pressurization.
2. To fix the machine required during the installation process is very easy and the machine will run smoothly.
3. A great stability is guaranteed as the vertical ring die granulator divides the material by the rotation of the pressure wheel which doesn't cause any heavy material or vibration.
4. The open-upward machine structure allows for better heat-dissipation and to become equipped with a set of air-cooled cloth bag for dust removal and automatic refueling.
5. With a strong enlarged shaft and a large cast steel bearing seat, the operation of the pellet machine is sound and reliable, as its large bearing doesn't bear any pressure, is not easy to break, and has a long service life.
6. In addition, with a mold with two layers, it reduces cost and increases efficiency.
Technical Parameters:
| Model |
Motor(KW) |
Ring die inner diameter(MM) |
Capacity(T/H) |
| EW450 |
55 |
450 |
0.8-1 |
| EW560 |
90 |
560 |
1.2-1.5 |
| EW600 |
110 |
600 |
1.8-2 |
| EW600A |
132 |
600 |
2-2.5 |
| EW700A |
160 |
700 |
2.5-3 |
| EW850 |
250 |
850 |
3-4 |
Applications:
The vertical ring die pellet machine is suitable for a wide range of raw materials, including wood chips, sawdust, wood bran, straw, bagasse, palm shell and more.
These materials are perfect for producing biomass pellet fuel without the need for the addition of any adhesive, as they are able to be processed through the necessary equipment.
These materials can also be used to produce a variety of wood processing and wood-based panel production products, such as sawdust, shavings, cup skin, sanding powder, waste wood, and branch wood.
Additionally, these materials may also be used for harvesting crop production, such as various straws.
