1-12mm Stainless Steel Floating Fish Feed Production Line Main Motor Power 5.5-132kw

1-12mm Stainless Steel Floating Fish Feed Production Line Main Motor Power 5.5-132kw

SS Floating Fish Feed Production Line

12mm Floating Fish Feed Production Line

Place of Origin:

Henan, China

Brand Name:

Zhongdebao

Certification:

CE, SGS, BV

Model Number:

DGP40-DGP200

Contact Us
Request A Quote
Product Details
Voltage:
380V/50HZ/3Phase
Main Motor Power:
5.5-132kw
Capacity:
100-500kg/h
Dimension:
Differernt Model With Different Size
Pellet Cutting Power:
0.75kw
Weight:
Differernt Model With Different Weight
Feeding System:
Automatic
Screw Conveyor Power:
0.75kw
Payment & Shipping Terms
Minimum Order Quantity
1
Price
negotiable
Packaging Details
Wooded package
Delivery Time
10 days
Payment Terms
T/T/western union ect, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100unit/month
Product Description

                                        1-12mm Stainless Steel Floating Fish Feed Production Line Main Motor Power 5.5-132kw

 Product Description:

Fish feed extruded pellet machine, also known as floating water pellet feed machine, floating pellet feed machine, pet pellet feed machine, soybean extruder, is widely used in aquaculture, pet breeding and cattle farms. After the feed is expanded, it can be fully cooked. After the animal eats it, it is easy to digest and gain weight quickly.
The gas in the feed extruder is extruded by the unequal-distance non-standard screw system, and is quickly filled with the feed. The feed reflows due to the shearing force, increasing the pressure in the machine chamber. With the friction between the stacker and the machine chamber, the material is fully mixed, extruded, heated, glued, gelatinized, and the structure changes, the original structure is destroyed, and the mechanical energy is converted into heat energy through the friction of the material in the chamber. , so that the material becomes a gel state with fluidity. When the material is extruded to the outlet, the pressure changes from high pressure to normal pressure instantly, and from high temperature to normal temperature instantly, causing water to evaporate quickly from the tissue structure, making it internally formed Numerous microporous structures, then pass through the cutting device, cut and cool to form puffed





Basic operation process of feed extruder
1. Turn on the power, first check whether the main engine motor, cutting motor, and feeding motor are turning correctly.
2. Pour the material into the hopper.
3. After starting the cutting motor, pour about a bottle of mineral water into the main shaft, and then start the feeding motor to feed evenly. The feed is extruded by the screw to achieve a fully cooked effect.

The feed made by the extruded pellet machine is sterilized, fully cooked, the animals are not easy to get sick after use, easy to digest, and the effect of fattening is obvious. It is a good choice for your breeding



The working principle of the extruder is very simple, but the performance and effect of the extruder are subject to various
factors. The most important factors include the quality of raw materials, heating temperature, pressure
and decompression speed, etc. If these factors are not properly controlled, it may lead to
The chemical effect is not good, affecting the quality and taste of aquatic feed.



Features:

  • Product Name: Floating Fish Feed Production Line
  • Material: Stainless Steel
  • Capacity: 100-500kg/h
  • Pellet Cutting Power: 0.75kw
  • Weight: Differernt Model With Different Weight
  • Main Motor Power: 5.5-132kw
  • Floating Fish Feeder Line
  • Fish Feeder Production Line
  • Floating Food Production Line

Technical Parameters:


Model  Main Power Cutter power  Capacity (kg/h)
65 22kw 0.75kw 200
70 37kw 1.1kw 300
80 55kw  1.5kw 500


Applications:

 1-12mm Stainless Steel Floating Fish Feed Production Line  Main Motor Power 5.5-132kw 0



1-12mm Stainless Steel Floating Fish Feed Production Line  Main Motor Power 5.5-132kw 1



1-12mm Stainless Steel Floating Fish Feed Production Line  Main Motor Power 5.5-132kw 2

1-12mm Stainless Steel Floating Fish Feed Production Line  Main Motor Power 5.5-132kw 3



Support and Services:

Floating Fish Feed Production Line Technical Support and Service

We provide an extensive support and service program for our Floating Fish Feed Production Line. Our service team consists of experienced engineers and technicians who are available to help you with:

  • Troubleshooting and repair of Floating Fish Feed Production Line
  • Installation and maintenance of Floating Fish Feed Production Line
  • Advice and technical assistance
  • Spare parts and consumables for Floating Fish Feed Production Line
  • Training sessions for operating and maintaining Floating Fish Feed Production Line

If you have any questions about our Floating Fish Feed Production Line, please feel free to contact us. We are always here to help!
