400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine

400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine

Biomass Tractor Pellet Machine

400PTO Tractor Pellet Machine Moving Roller

400PTO Saw Dust Pellet Machine

Place of Origin:

Henan, China

Brand Name:

Zhongdebao

Certification:

CE, SGS, BV

Model Number:

PTO 400

Contact Us
Request A Quote
Product Details
Raw Material:
Sawdust
Work Way:
Moving Roller
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Customize
Packaging Details
Wooded package
Delivery Time
15days
Payment Terms
T/T/western union ect
Supply Ability
100unit/month
Product Description



Moving Roller Biomass Tractor Run Sawdust 400PTO Wood Pellet Machine Customized

Product Description:



PTO Pellet Mill is a reliable and efficient choice for farmers and small-scale wood pellet production, as it runs on a tractor with 10 to 80hp, without needing any external power source. With a relatively low investment cost, it is a highly economical solution for biomass pellet production. With its easy installation, use and maintenance, PTO Pellet Mill can also offer long-term reliable service and reduce the overall operating cost.



The 400PTO model wood pellet machine suit for Power of matching tractor: 55 horsepower or more. Material of die pressing roller: 42CrMo alloy steel



How to use the pellet machine:



1. First check whether the screws of each part of the pellet machine are tightened, and then loosen the two adjusting screws at both ends of the pressure wheel, and then start the motor, and carefully check whether there is any bad phenomenon when the pellet machine is rotating.

2. If there is no problem, then tighten the two pressure roller adjustment screws, and then start the machine. The next step is to put in the materials to be ground one after another, and repeat the grinding several times until the template holes are smooth and all the materials are discharged.


3. Before the pellet machine stops, the feeding must be stopped first, and after the materials in the silo are processed, add some oily matter and press them into the hole of the template, so as to keep the hole lubricated and ensure that it will not appear in the next use. Congestion



Technical Parameters:

Model
ZLSP400P
Capacity for wood pellet
400600 KG/H
Packing Size(cm)
135*56*122
Net/Gross Weight(kg)
437/485
Moisture
10%-15%



What to pay attention to when using the pellet machine

1. When using the pellet machine, it is necessary to prohibit overloading production, because overloading will have a certain impact on the direct deceleration of the pellet machine and the motor, so this must be avoided. If it occurs, repair and replace the damaged parts immediately.

2. After using the pellet machine, it is necessary to take out the roller and clean the machine carefully, and then store it for the next use. If it is not used frequently, the machine should be stored and kept clean, and the outer layer of the machine should be covered with a layer of oil cloth.


3. Add some oil to the transmission on a regular basis. All transmission parts must be maintained with lubricating oil within a fixed period of time to ensure a longer service life of the machine.

4. If the pellet machine is used for a long time, it is necessary to check the mechanical parts at a fixed time, including rollers, molds, gears and bearings. If any problems with these parts are found, they should be replaced immediately, and some accessories in the pellet machine should also be fixed and checked for looseness.



Customization:

PTO Pellet Mill

Brand Name: Zhongdebao

Model Number: PTO 200-400

Place of Origin: Henan, China

Certification: CE, SGS, BV

Minimum Order Quantity: 1

Price: Customize

Packaging Details: Wooded package

Delivery Time: 10 days

Payment Terms: T/T/western union ect

Supply Ability: 100unit/month

Power: PTO Or Diesel Engine

Capacity: 80-1200kg/h

Tractor Horsepower : 10-80hp

Name: PTO Pellet Mill

Die Material: Alloy Steel



Biomass Pellet Machine, Farm Pellet Machine, Portable Pellet Mill



FAQ:

Q1: What is the brand name of the PTO Pellet Mill?
A1: The brand name of the PTO Pellet Mill is Zhongdebao.

Q2: What is the model number of the PTO Pellet Mill?
A2: The model number of the PTO Pellet Mill is PTO 200-400.

Q3: Where is the PTO Pellet Mill manufactured?
A3: The PTO Pellet Mill is manufactured in Henan, China.

Q4: What certifications does the PTO Pellet Mill have?
A4: The PTO Pellet Mill has CE, SGS, and BV certifications.

Q5: What is the minimum order quantity of the PTO Pellet Mill?
A5: The minimum order quantity of the PTO Pellet Mill is 1.

400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine 0400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine 1400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine 2

400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine 3400PTO Biomass Tractor Pellet Machine Moving Roller Saw Dust Pellet Machine 4
