100kg/H Bbq Wood Pellet Maker Biomass Wood Pellet Machine For Home Use

100kg/H Bbq Wood Pellet Maker Biomass Wood Pellet Machine For Home Use

100kg/H Bbq Wood Pellet Maker

Wood Pellet Maker Biomass

100kg/H Wood Pellet Machine For Home Use

Place of Origin:

China

Brand Name:

Zhongdebao

Certification:

CE,SGS

Model Number:

EWPM

Contact Us
Request A Quote
Product Details
Product Name:
Wood Pellet Machine
Warranty:
12 Months
Voltage:
380 V (accept Customized According To Your Local Voltage)
Pellet Size:
Adjustable,6-12mm
Type:
Wood Pellet Mill Machine
Raw Material:
Sawdust,rice Husk,straw Etc,wood Waste And So On,Wood
Application:
Make Biomass Pellets,wood Pellet/Animal Feed,biomass Pellet Making,biomass Pellet Mill,wood Sawdust Pellet Making
Usage:
Biomass Industry
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiable
Packaging Details
Standard wood case packing or accept customized
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 sets per month
Product Description

Home Use 100kg/H Capacity Wood Pellet Maker For Bbq Wood Pellets Machine

product description



The granulator has different moisture requirements for different raw materials, usually the sawdust ZLSP-D dynamic disc granulator requires
The raw material moisture is 10%-18%, and the moving roller series granulator requires the raw moisture to be 10%-14%, and the raw material is mixed evenly.

Granulation requires that the maximum size of the raw material should not exceed the diameter of the die hole. If the die hole is 6mm, the maximum size of the raw material should not exceed 6mm. The user should control the size of the raw material according to the die hole diameter of the die plate.

A single raw material can be used, and different raw materials can also be mixed, but hard objects such as iron blocks and stones must not be mixed into the raw materials, otherwise the machine will be damaged.

Features




  • 1. High granulation efficiency: The biological granulator adopts a high-speed rotating mold and roller structure, which can quickly compress biomass materials into particles of a certain size, which greatly improves the granulation efficiency.
  • 2. Low cost: The manufacturing cost of the biological pellet granulator is relatively low, and the cost of use is also relatively low, because most biomass materials can be used as raw materials for granulation, and some waste or waste can be added during the granulation process Material treatment products, reducing production costs.
  • 3. Easy to use: The operation of the biological particle granulator is simple and convenient, just follow the operating instructions.
  • At the same time, the maintenance of the equipment is relatively easy, just follow the operating instructions for maintenance, which reduces the cost of use.
  • 4. Wide range of application: The bio pellet granulator is not only suitable for the production of biomass pellet fuel, but also can be used in feed, fertilizer and other fields.
  • Due to its high granulation efficiency, low cost, and convenient use, the biological granulator is widely used in the field of biomass granulation.


Technical Parameters




Wood Pellet Mill

Model Capacity Power Weight
EWPM- 200 80-120 kg/h 7.5 kw 300 kg
EWPM- 300 200-300 kg/h 22 kw 550 kg
EWPM- 400 400-500 kg/h 30 kw 850 kg
EWPM- 450 600-700 kg/h 45 kw 1150 kg
EWPM- 550 700-800 kg/h 55 kw 1800 kg











Usage


1. Biomass pellet fuel: Biomass pellet granulator can make various biomass materials, such as sawdust, straw, reed, bamboo, etc., into biomass pellet fuel with consistent specifications and stable quality.
Biomass pellet fuel can replace traditional fuel and reduce energy pollution and consumption, which has very important practical significance.
2. Feed field: The biological pellet granulator can make various feed raw materials, such as corn, soybean, wheat bran, etc., into feed pellets with consistent specifications.

100kg/H Bbq Wood Pellet Maker Biomass Wood Pellet Machine For Home Use 0



100kg/H Bbq Wood Pellet Maker Biomass Wood Pellet Machine For Home Use 1

100kg/H Bbq Wood Pellet Maker Biomass Wood Pellet Machine For Home Use 2

100kg/H Bbq Wood Pellet Maker Biomass Wood Pellet Machine For Home Use 3
